Burkert 8693 - Information on the Display

33
Type 8692, 8693
english
Control and display elements,
operating modes
1.2 Configuration of the keys
The assignment of the 4 keys on the control panel differs depending on the operating status (AUTOMATIC / MANUAL) or
operating level (Operate process / Parameterization and Configuration) of the positioner.
The configuration of the keys is represented in the lower grey bar on the display panel.
The description of the operating statuses (AUTOMATIC / MANUAL) and the operating levels (Operate process /
Parameterization and Configuration) can be found in the chapters entitled “Operating modes” and “Operating levels”.
Key Configuration (indicated in the lower bar) Operating status / Operating level
Up / down arrow key Change the display
(e.g. POS-CMD-TEMP-...)
AUTOMATIC / Operate process
OPN - CLS (OPEN - CLOSE)
manual opening and closing of the actuator
MANUAL / Operate process
Scroll up and down the menus AUTOMATIC or MANUAL /
Parameterization or Configuration
+ and -
increase or reduce numerical values
AUTOMATIC or MANUAL /
Parameterization or Configuration
+ and ←
adjust numerical values by individual digits
AUTOMATIC or MANUAL /
Parameterization or Configuration
Left selection key Switch to the Parameterization level (MENU)
Note:
the key must be pressed for approx. 3s (Count-
down: 2 bars converge on the display panel)
AUTOMATIC or MANUAL /
Operate process
EXIT (BACK)
Operate process on the operating level
AUTOMATIC or MANUAL /
Parameterisation
EXIT (BACK)
from a menu option on the operating level Param-
eterization or Configuration
AUTOMATIC or MANUAL /
Parameterization or Configuration
ESC
Leave a menu
AUTOMATIC or MANUAL /
Parameterization or Configuration
STOP
End a sequence
AUTOMATIC or MANUAL /
Parameterization or Configuration
Right selection key Switch between AUTOMATIC and MANUAL
mode
Operate process
Select, activate or deactivate a menu option
(ENTER, SELEC, OK, INPUT)
AUTOMATIC or MANUAL /
Parameterization or Configuration
EXIT (BACK)
from a menu option on the operating level Param-
eterization or Configuration
AUTOMATIC or MANUAL /
Parameterization or Configuration
RUN
Start a sequence
AUTOMATIC or MANUAL /
Parameterization or Configuration
STOP
End a sequence
AUTOMATIC or MANUAL /
Parameterization or Configuration
