Start-up, operation
position controller Type 8692
2.2 Factory settings of the position controller
Function Factory setting Function Factory setting
ACTUATOR SINGLE or DOUBLE*
INPUT 4-20 mA
CHARACT linear
DIR.CMD Rise
CUTOFF Min 0 %
Max 100 %
DIR.ACT Rise
SPLTRNG Min 0 %
Max 100 %
X.LIMIT Min 0 %
Max 100 %
X.TIME
Open (1s) Values of X.TUNE determined
Close (1s) Values of X.TUNE determined
After running SET.FACTORY: 1s
BINARY. IN SafePos
BIN. IN type normally opened
X.CONTROL
DBND 1.0 %
KXopn (1) Values of X.TUNE determined
KXcls (1) Values of X.TUNE determined
After running SET.FACTORY: 1
SECURITY
Access Code 1 0000
SAFEPOS 0 %
SIG.ERROR
SP/CMD Input Error off
OUTPUT**
OUT ANALOGUE Out POS
OUT type 4-20 mA
OUT BIN1 Out DEV.X
Lim. DEV.X 1.0 %
OUT.BIN1 type normally opened
OUT BIN2 Out DEV.X
Lim. DEV.X 1.0 %
OUT.BIN1 type normally opened
2.3 Specifying the Basic Settings
When starting up the positioner for the first time, implement the following basic settings:
Specify the selected unit signal input for the set-point value default (
→ INPUT)
(4 – 20 mA, 0 – 20 mA, 0 – 10 V or 0 – 5 V).
Start automatic adjustment of the position controller to the particular operating conditions (
→ X.TUNE).
The exact description of the functions INPUT and X.TUNE can be found in the chapter entitled “Description of the
functions of the main menu”.
The basic settings for the positioner are implemented at the factory. During start-up, however, it is essential to input
the unit signal (INPUT) and run X.TUNE . Using the X.TUNE function, the positioner automatically determines the
optimum settings for the current operating conditions.
If the X.CONTROL is in the main menu while the auxiliary function X.TUNE is running, the position controller dead
band DBND is determined automatically depending on the friction behaviour of the actuator (see chapter entitled
“Auxiliary functions - X.CONTROL”)
* preset at the factory
** option only
