134
Type 8692, 8693
english
PROFIBUS-DP
Address XXX
Input the device address
Press the arrow keys (+/-) to set values from 0 – 126;
Confirm by pressing the selection key on the right (OK).
BUS FAIL
SafePos off
SafePos on
Activate to approach the safety position if the bus communication fails
The position is approached which corresponds to the set-point value last transferred.
(Default setting)
If SafePos on is set, the following configurations may occur:
Active • SAFEPOS
menu option If a fault is detected in the bus communication, the drive moves to the lower
SAFEPOS set position.
Inactive • SAFEPOS
menu option If a fault is detected in the bus communication, the drive moves to the end
position which it would specify in the isolated state.
BUS PDI
Position
CMD
Process value *
Setpoint *
Temperature
Operation mode
Errors
P.CONTRL active **
Selection of the process values which are to be transferred by the positioner to the controller
(master).
Press the selection key on the right (ENTER) either to activate (x) or deactivate ( ) the re-
spective process value.
For meaning of the process values see table PDI: Process Data Input.
BUS PDO
CMD / Setpoint *
Operation mode
Error reset
P.CONTRL active **
Selection of the process values which are to be transferred by the controller (master) to the
positioner.
Press the selection key on the right (ENTER) either to activate (x) or deactivate ( ) the
respective process value.
For meaning of the process values see table PDO: Process Data Output.
7 FUNCTIONAL DEVIATIONS FROM THE STANDARD MODEL
It is possible to switch between the MANUAL and AUTOMATIC operating states on the process operating level either via the
keyboard on the positioner or via the bus.
It is no longer possible to switch between MANUAL / AUTOMATIC on the keyboard if an operating mode (under PDO MODE)
is transferred to the positioner via the bus.
* only for type 8693 and when process controller activated
** only for type 8693
