33
Parts order
Type 2000, 2002, 2012
Type2012,actuatorsizeCtoH(40–125mm)
• Seal set for actuator
consistingofthesealingandwearingpartsoftheactuator.
• Valve set
consistsofswivelplate,pinandgraphiteseal.
• Valvettings
consistsofswivelplate,pin,graphitesealandvalveseat.
Seal set actuator
Valve set
Valvettings
Type2012,actuatorsizeCtoH
Figure 11: Replacement part sets Type 2012, actuator size C to H (40 – 125 mm)
english

Burkert 2000 Specifications

General

Model	2000
Manufacturer	Burkert
Ambient Temperature	-10 to +60 °C
Protection Class	IP65
Operating Temperature	-10 to + °C
Seal Material	FKM
Operating Pressure	0- bar
Fluid Temperature	-10 to + °C
