Parts order
Type 2000, 2002, 2012
Type2012,actuatorsizeK(175mm),L(225mm)
• Sealsetpackinggland
consistofwearingpartsofthestungbox,graphiteseal.
• Valve set
consistsofswivelplate,pinandgraphiteseal.
• Valvettings
consistsofswivelplate,pin,graphitesealandvalveseat.
• Seal set swivel plate
consistsofgraphiteseal,pinandPTFEgasket.
Sealsetpackinggland
Seal set swivel plate
Valvettings
Valve set
Valve seat
Type2012,actuatorsizeK,L
Figure 12: Replacement part sets Type 2012, actuator size K (175 mm), L (225 mm)
