6
5 TECHNICAL DATA
5.1 Standards and directives
The device complies with the relevant EU harmonisation legislation.
In addition, the device also complies with the requirements of the
laws of the United Kingdom.
The harmonised standards that have been applied for the con-
formity assessment procedure are listed in the current version of
the EU Declaration of Conformity/UK Declaration of Conformity.
5.2 Operating conditions
WARNING!
Risk of injury from discharge of medium and pressure.
▶ If the device is used outdoors, do not expose it unprotected to
the weather conditions.
▶ Avoid heat sources which may cause the allowable tempera-
ture range to be exceeded.
Ambient temperature -10 – +55 °C
Degree of protection IP65 in accordance with EN 60529 with
cable plug
5.3 Mechanical data
Dimensions See data sheet
Port connection Type 6014 G1/8, G1/4, ange
Type 6014P G1/8, G1/4
Hollow screw G1/8, G1/4
Materials
Body Type 6014 brass, stainless steel 1.4305,
polyamide (PA, ange)
Type 6014P brass, polyamide (PA)
Hollow screw Type 6014P brass,
stainless steel 1.4301/304
Base plate Type 6014P aluminium anodized or IXEF
Sealing Type 6014 FKM, EPDM on request
Type 6014P FKM
english
