english
Operating Instructions-No. 803 150
11
Block Assemblies
Type 6518, 6519
and
Modular Pneumatic Basic Rail
Type MP07
Contents:
1 GENERAL SAFETY INSTRUCTIONS 12
2 SYMBOLS USED 12
3 GENERAL DESCRIPTION 13
3.1 Valve Construction 13
3.2 Valve operations of the Type 6518 / 6519 13
3.3 Media 14
3.4 Electrical connections 14
4 INSTALLATION, INITIALISATION AND SERVICE 15
4.1 Setting up block assemblies using the modular pneumatic rail
type MP07 15
4.2 Dismantling the module 16
4.3 Other possible uses of the connecting module, - right-hand - 16
4.4 Mounting the valve block 16
4.4.1 Standard rails 16
4.4.2 Wall mounting 17
4.5 Mounting single valves 17
4.5.1 Plug-in connections 17
4.5.2 Dismantling the plug-in connections 18
4.6 Measures to be taken before putting into service 18
4.7 Pulse operation 18
4.8 Faults 19
5 NOTES 20
