• Standard rail 35 x 15 DIN 50022 (Standard)
• Standard rail 75 x 25 DIN 50023
NOTE
Secure the valves to the base module using 2 M4 screws each.
(Tightening torque max. 1.5 Nm).
Mount the complete valve block onto the wall or the standard rail.
Connect the supply and working lines.
Make the electrical connections to the pilot valves: in doing this, observe the values
given on the rating plate!
4.2 Dismantling the module
Unlatch both locking hooks by using a screwdriver on the end dismantling-
grooves.
Remove the block part / module sideways.
4.3 Other possible uses of the connecting module,
- right-hand -
• As a separation module for special applications when building up several pressure
levels in a single block
• Additional supply lines for larger valve blocks
Installation
Hang the valve block onto the upper groove of the standard rail.
Latch the lower clamp into the standard rail.
Firmly tighten the screws on the clamp.
Dismounting
Loosen the clamping screws (by about 4 revolutions).
Remove the block upwards from the standard rail.
Where necessary, break out the rated break-points of
Ports 1, 3 and 5 and the upper pilot venting.
NOTE
4.4 Mounting the valve block
4.4.1 Standard rails
When using the 75 x 25 DIN 50023 standard rail, change
over the pre-assembled screws with clamps and springs
as necessary.
