Voltage supply 12-36 VDC, filtered and regulated
Current consumption
(with sensor) ≤ 50 mA
Protection against polarity
reversal yes
Protection against voltage
peaks yes
Output data NPN and PNP transistors, open collector, 100 mA max.,
NPN output: 0,2-36 VDC and PNP output: power supply voltage
frequency up to 300 Hz, duty cycle = 1/2 ±10%
(frequency = K factor x flow rate; the K factor value must be taken from the
instruction manual of the fitting)
Protection against
short-circuits yes
Cable length max. 50 m, shielded (up to 500 m, depending on the cable impedance and the
current consumption
Power supply 12-36 VDC, through a Bürkert transmitter, filtered and regulated
Current consumption
(with sensor) ≤ 0,8 mA
Protection against polarity
reversal yes
Protection against voltage
peaks yes
Output data NPN transistor, open collector, 10 mA max.,
frequency up to 300 Hz, duty cycle of 1/2 ±10%
(frequency = K factor x flow rate; the K factor value must be taken from the
instruction manual of the fitting)
Protection against
short-circuits yes
Cable length max. 50 m, shielded
Cable cross section max. 1.5 mm
2
Electronic housing PE-HD
Nut PC
EN175301-803 fixed
connector and cable plug PA (contacts in brass, electro-silver plated)
Finger holder, paddle-wheel PVDF
Axis and bearings ceramics
Gasket FKM, standard (EPDM on request)
