The 8020 flowmeter can be installed in any pipe using our specially designed S020 fitting
system.
The sensor can be installed whatever the inclination of the pipe.
When mounting fitting , make sure to respect the instructions described in § 2.1
and within the instruction manual of the fitting. Then:
- Insert nut
into fitting and let plastic ring snap into guide bush .
- Carefully insert the sensor into the fitting. If installed properly, the
sensor cannot be rotated.
- Tighten the sensor to the fitting using nut
.
