Technical data
6.1.4 Material data of a 8025 Batch in compact version
Part Material
Housing /cover, lid, nut PC
Frontfoil / Screws Polyester / Stainless steel
Cable glands PA
Identification label Polyester
Wetted parts
• Sensor holder / Paddle-wheel • PVDF
• Axis and bearings of the paddle-wheel • Ceramics
• Seal • FKM (optional EPDM)
• Fitting S020 • Refer to the Operating Instructions of the fitting
6.1.5 Dimensions of a 8025 Batch in compact version
→ Please refer to the technical data sheets regarding the dosing controller type 8025 Batch in compact version,
available at: www.burkert.com
6.1.6 Electrical data of a 8025 Batch in compact version
12...36 V DC power supply
• filtered and regulated
• SELV circuit (safety extra low voltage), with a safe
energy level
• oscillation rate: ±10%
Power source (not supplied)
for versions supplied with 12..36 V DC
• limited power source according to §9.4 of
EN 61010-1 standard
• or class 2 source according to UL 1310/1585 and
EN 60950-1 standards
115/230 V AC power supply
• frequency • 50/60 Hz
• supplied voltage • 27 V DC, regulated
• Maximum current • 125 mA
• integrated protection • 125 mA time-delay fuse
• power • 3 VA
Maximum current consumption version
12...36 V DC
100 mA
Maximum current consumption version
115/230 V AC
55 mA
Pulse output (transistor) DO1 and DO4
polarized, potential-free
• type • NPN/PNP (wiring dependant)
• DO1 function • pulse output (can be configured and parametered)
• DO4 function • dosing state (can be configured and parametered)
• frequency (f) • 0,6...300 Hz
• electrical data • 5...36 V DC, 100 mA max.,
voltage drop 2,7 V DC at 100 mA
• duty cycle • >0,45
