Operating and functions
→ To interrupt the dosing, press
ENTER
: the valve connected to output DO2 and possibly the valve connected
to output DO3 close, the device state LED flashes at a 1 Hz-frequency and the DO4 output (if configured to
transmit the device state, see chap. 10.7.26) generates a 1 Hz-frequency.
CONtiNUE
RESEt
→ To continue the dosing via the digital inputs:
• let at least one of the 3 digital inputs, DI1, DI2 or DI3, activated
• then send a pulse on DI4.
→ To continue the dosing via the navigation keys:
• display "CONTINUE" by pressing key
0......9
or ,
• then press key
ENTER
.
→ To abort the dosing via the digital inputs:
• activate then deactivate one of the 3 digital inputs, DI1, DI2 or DI3, to make sure that "RESET"
is displayed,
• then send a pulse on DI4.
→ To abort the dosing via the navigation keys:
• display "RESET" by pressing key
0......9
or ,
• then press key
ENTER
.
37.8 L
The countdown of the dosing quantity continues.
V1
The device is ready for a new dosing.
Fig. 49 : Interrupting the dosing, in dosing mode "EXT.+LOC."
