Technical data
Type 8710, 8711, 8713, 8715
6. TECHNICAL DATA
attention
Risk of injury from pressure and discharge of fluid.
Important device-specific technical data is indicated on the name plate and the calibration plate (see chap. 6.1).
• Observe the permitted fluid according to the name plate (depending on seal material).
• Observe the permitted pressure range on the calibration plate of the device.
6.1. Markings on the device
Examples:
8701 20.0 Nl/min
Made in France
00210166
W49MM
24V DC 5W DP
CH4
S/N 1004
FKM
Name plate
Calibration data 00182381
QC passed: 25/11/2011
P1 : 10,00 barg
Medium 1
P1 : 10,00 barg
Medium 2
Mounting: horizontal upright
Calibration plate
Fig. 2: Name plate, calibration plate
