20
Technical data
Type 8700, 8701, 8703, 8705
6.7. Electrical data
6.7.1. Electrical data for types 8703 / 8705 / 8713 / 8715
Specification Type
Power supply 24 V DC ± 10%; residual ripple < 2% (5% for UL devices)
Power supply (not provided) for UL devices Power supply limited to class 2
Type of device 8703 / 8705 8713 8715
Power required (max. in Watt) 2.5 11.5 7.5
Binary input (configurable) 1, active at the trailing edge, to be connected to DGND for activation
Communication interface RS485 supporting the MODBUS protocol
Relay output (configurable) 1, potential-free changer, 60 V, 1 A, 60 VA
LEDs (configurable) 3 LEDs, status display for Power, Communication, Error
Electrical connections Sub-D 9-pin male fixed connector
