Technical data
Type 8700, 8701, 8703, 8705
4,5
2x
Ø6
0
14
17,75
14
17,75
0
10
26
58,5
81 92 97
107
58,5
35,5
4x
Ø 4,5
35,5
2x
Ø 8,8
43
0
5
30
43,5
84
115,5
M4
Fieldbus versions:
CANopen, DeviceNet = 18
PROFIBUS DP = 16,5
Fig. 7: Dimensions of MFM with flanges, types 8700 and 8701,
and MFC with flanges, types 8710 and 8711
Weight aluminium (kg) Weight stainless steel (kg)
ca. 0.8 ca. 1.1
3,5
0
12,5
30
85
114
Fig. 6: Dimensions of MFM with metal housing, types 8700 and
8701, and MFC with metal housing, types 8710 and 8711
Weight aluminium (kg) Weight stainless steel (kg)
ca. 0.8 ca. 1.1
