16
Technical data
Type 8700, 8701, 8703, 8705
3,5
0
85
114
Fig. 10: Dimensions of MFC with metal housing and external
solenoid valve, type 8711
Weight aluminium (kg) Weight stainless steel (kg)
ca. 1.2 ca. 1.5
3,5
0
10
97
107
28 20
2x M4
1,7
0
12,5
30
62,5
81,5
A
Fig. 11: Dimensions of MFM types 8703 and 8705 and MFC
types 8713 and 8715
Weight aluminium (kg) Weight stainless steel (kg)
ca. 0.8 ca. 1.1
English
