Operation and function
Type 8710, 8711, 8713, 8715
Function Description
Actuate Autotune
Start of Autotune function for optimization of
the control settings to the conditions available
in the system
(see chap. 8.3).
Switch to
specification 2
The calibration curve saved under Gas 2 as
well as all settings entered there are used.
Totalizer Reset The integrated totalizer (quantity integrator) is
reset.
Start set-point
value profile
Start of the saved set-point value profile (see
chap. 8.3).
Control mode
Enables the solenoid valve to be opened at a
given value
(see chap. 8.3).
Correct safety
value*
The safety value stored in the device is used
as a flow-rate set-point value.
In this case, the flow-rate set-point value
received by the analogue input or field bus is
ignored.
Close valve
completely*
Valve completely closed.
In this case, the flow-rate set-point value is
ignored.
Open valve
completely*
Valve completely opened.
In this case, the flow-rate set-point value is
ignored.
Table 2: Possible binary input functions.
* The operating principle of the binary input (active / inactive) can
be selected for these functions
8.2.3. Relay outputs
The MFM / MFC have a relay output to indicate the operating state,
limit values outside the maximum / minimum or a fault.
Output Assignement
Relay output y2 Limit
Table 3: Relay output default assignment
Function Description
Not used No function is assigned to the relay output
Power ON The device is energized.
Autotune activated The Autotune function is in progress.
Gas 1 or 2 active Calibration curve 1 or 2 is used.
User-defined
calibration active
The device operates at the calibration
adjusted by customer.
Binary input 1 or 2
active
Binary input 1 or 2 has been activated.
Activate relay
output by field bus
The status of the relay outputs is specified via
the field bus or the serial interface.
Correct safety
value active
The safety value is used as the set-point
value.
Set-point value
profile active
The set-point value profile stored in the device
is used as the set-point value.
Control mode
active
The control mode is active, i.e. the solenoid
valve is opened at a given value.
Close valve
completely active
The close valve completely function is
activated.
