CONNECTIONS
The connections of the CD-Player 102 are located on the rear panel of the device. During the connecting procedure
all individual components of your playback system must be turned off.
There are various possibilities to connect the CD player, depending upon the kind of audio components and auxiliary
devices used. For the best connections please also refer to the owner’s manual of your audio components or
auxiliary devices. The following explains the various hookup possibilities:
Digital Outputs The player provides two digital outputs to connect to a digital amplifier:
The terminal TOTX (26) sends optical signals via optical cable with TOSHIBA-norm plugs.
The terminal RCA (25) requires a 75ohms coax cable with RCA plugs. Choose whichever
connection sounds best to you if your amplifier allows both types of hookup.
CAUTION: The terminal RCA (25) must not be connected to the analog input of an amplifier
because this could damage the amp or the loudspeakers.
Digital Inputs The CD player 102 offers two digital inputs for the connection of external digital source
components such as DAT recorders or CD players:
The terminal RCA (27) receives electronic signals and require 75Ω coax cable with RCA
plugs. The terminal TORX (28) receives optical signals and requires an optical cable with
plugs according to TOSHIBA norm.
Choose whichever connection sounds best to you if your amplifier allows both types of
hookup.
