WIRE NO. IN
FIG. 11.7
WIRE MARKING
WIRE NO. IN
FIG 11.7
WIRE MARKING
1 RD J8-8/P4-1, P4-1/SUP-1 20 BK SPL BK-1/P1-2, P1-2/120V
2 VI J9-4/P4-2, P4-2/FLUE-1 20a BK SPL BK-1/L2-1
3 RD J2-2/P4-3, P4-3/FAN-1 20b BK J4-2/SPL BK-1
4 R/G J8-9/P4-4, P4-4/SUP-2 20c BK J4-4/SPL BK-1
5 V/G J9-5/P4-5, P4-5/FLUE-2 20d BK J4-6/SPL BK-1
6 WH J2-1/P4-6, P4-6/FAN-2 20e BK SPL BK-1/P3-8, P3-8/B1-1
7 GY J8-10/P4-7, P4-7/SUP-3 21 GY P2-6/P3-9, P3-9/THERM-1
8 GY J9-6/P4-8, P4-8/FLUE-3 22 GR J4-10/P3-10, P3-10/SPL GR-1
9 BK J2-3/P4-9, P4-9/FAN-4 22a GR SPL GR-1/B1-3
10 BL J8-4/P4-10, P4-10/RET-1 22b GR SPL GR-1/GND
11 BL/G J8-5/P4-11, P4-11/RET-2 23 OR J1-2/P3-11, P3-11/SPL OR-1
12 BL J2-4/P4-12, P4-12/FAN-5 23a OR SPL OR-1/TRAP
13 BL/G J6-2/P3-1, P3-1/APS 23b OR SPL OR-1/FLAME
14 YE L3-2/SPL Y-1 24 GY J6-3/P3-12, P3-12/SPL GY-1
14a YE J8-2/SPL Y-1 24a GY SPL GY-1/FLOW-1
14b YE SPL Y-1/P3-2, P3-2/GAS-2 24b GY SPL GY-1/SPS
15 GR J4-12/P3-3, P3-3/IGN GND 25 GY SPS/THERM-2
16 RD J5-2/P3-4, P3-4/GAS-1 26 BL J4-3/P5-7, P5-7/ZV-1
17 BL L3-1/SPL BL-1 27 RD J4-5/P5-1, P5-1/BP-1
17a BL SPL BL-1/J8-1 28 YE J8-3/P2-4
17b BL SPL BL-1/P2-1 29 YE J10-7/P2-2
17c BL SPL BL-1/P3-5, P3-5/APS 30 RD J10-8/P2-3
17d BL SPL BL-1/P5-2, P5-2/DFS-3 31 BR J7-7/P5-5, P5-5/DFS-2
18 GY J5-1/P3-6, P3-6/FLOW-3 32 YE SYS PUMP/P1-5, P1-5/J4-7
19 WH NEUT/ P1-1, P1-1/SPL W-1 33 Y/G J9-1/P5-9, P5-9/DS
19a WH SPL W-1/L2-3 34 Y/G J9-2/P5-6, P5-6/DS
19b WH SPL W-1/P3-7, P3-7/B1-2 35 OR J3-1/SPL OR-1
19c WH SPL W-1/P5-4, P5-4/SPL W-1 35a OR SPL OR-1/ +RD
19d WH P5-4/SPL W-1, SPL W-1/BP-2 35b OR SPL OR-1/ +SD
19e WH SPL W-1/ZV-2 36 VI J3-2/SPL VI-1
36a VI SPL VI-1/ -RD
36b VI SPL VI-1/ -SD
37 BL J3-3/ 5V+
38 PI J3-6/ 5V-
USE WIRE CODE ON CONNECTIONS DIAGRAM TO DETERMINE COLOR.
Table 11.8: Internal Wire Connection Markings Cross Reference Table
