57
Item
No.
Description Part No. MST288 MST396 MST513 MST629
1. BARE BOILER ASSEMBLY
1A Front Section, Machined 100569-01 1 1 1 1
1B Center Section, Machined 100571-01 1 1 2 3
1C1 Rear Section (Htr.), Steam, Machined 100573-01 1 1 1 1
1C2 Rear Section (Non-Htr.), Steam, Machined 100676-01 1 1 1 1
1D1 Slip Nipple, 22-B Steel 806600375 2 2 3 4
1D2 5" Cast Iron Slip Nipple 7066003 2 2 3 4
1E
Upper Tie Rod, 3/8" -16 x 16" Lg. 80861075 1 1 --- ---
Upper Tie Rod, 3/8" -16 x 21-1/2" Lg. 80861033 --- --- 1 ---
Upper Tie Rod, 3/8" -16 x 27-1/2" Lg. 80861014 --- --- --- 1
1F
Lower Tie Rod, 3/8" -16 x 15" Lg. 80861016 1 1 --- ---
Lower Tie Rod, 3/8" -16 x 20-3/4" Lg. 80861012 --- --- 1 ---
Lower Tie Rod, 3/8" -16 x 27" Lg. 80861018 --- --- --- 1
1G 3/8" Flat Washer, USS, Plain 80860600 4 4 4 4
1H 3/8" -16 Heavy Hex Nut, Plain 80860400 4 4 4 4
1J
Spanner Bar w/Threaded Inserts,
1-1/4" x 1-1/2" x 20-3/8" Lg.
100012-02 2 2 --- ---
Spanner Bar w/Threaded Inserts,
1-1/4" x 1-1/2" x 26-3/8" Lg.
100012-03 --- --- 2 ---
Spanner Bar w/Threaded Inserts,
1-1/4" x 1-1/2" x 32-3/8" Lg.
100012-04 --- --- --- 2
1K Carriage Bolt, 3/8" -16 x 1-1/4" Lg., Plated 100215-01 4 4 4 4
1L Cap Screw, 5/16" -18 x 7/8" Lg., Plated 80861371 4 4 4 4
1M Flat Washer, 5/16", USS, Plated 80860611 4 4 4 4
1N Hex Nut, 5/16 -18, Serrated Flange, Plated 80860443 4 4 4 4
1P Hinge Bracket 100014-01 1 1 1 1
1Q 5/16" -18 x 3/4" Lg. Cap Screw, Plated
Hinge Bracket
80861340
2 2 2 2
Mount Burner 3 3 3 3
1R Cast Iron Burner Swing Door (Only) 100071-01 1 1 1 1
To Next Page
