Burnham MEGASTEAM MST513 User Manual

6
TABLE 1A: DIMENSIONAL DATA (SEE FIGURE 1)
TABLE 1B: RATING DATA
Boiler
Model No.
Dimensions (See
Figure 1)
Water Content (To Normal
Water Line) - Gallons
Heat Transfer
Surface Area
- sq. Ft.
Actual Shipping
Weight (LB.)
"A" "B" "C"
With Tankless
Heater
Non-Heater
MST288 22-5/8" 24" 6" 15.3 14.9 20.29 607
MST396 22-5/8" 24" 6" 15.3 14.9 20.29 607
MST513 28-5/8" 30" 6" 19.7 19.3 27.29 744
MST629 34-5/8" 36" 7" 24.1 23.8 34.29 881
NOTE: 1: Maximum Working Pressure: Steam - 15 PSI
Boiler
Model
No.
Burner Capacity
I=B=R NET
Ratings
Minimum Chimney
Requirements
AFUE
%
GPH MBH
DOE Heating
Capacity MBH
Steam
MBH
Steam
Sq. Ft.
Round
In. Dia.
Rectangle
In. x In.
Height
Ft.
MST288 0.75 105 92 69 288 6 8 X 8 15 86.0
MST396 1.05 147 127 95 396 6 8 X 8 15 86.0
MST513 1.35 189 164 123 513 7 8 X 8 15 86.0
MST629 1.65 231 201 151 629 7 8 X 8 15 86.0

Burnham MEGASTEAM MST513 Specifications

General

Brand	Burnham
Model	MEGASTEAM MST513
Category	Boiler
Language	English
