Burnham MEGASTEAM MST513 - Page 59

59
Item
No.
Description Part No. MST288 MST396 MST513 MST629
1. BARE BOILER ASSEMBLY (Continued)
1S
Burner Swing Door Insulation (Less Pockets) 100039-01 1 1 1 ---
Burner Swing Door Insulation (With Pockets) 100039-02 --- --- --- 1
1T 5/8" Dia. Rope Gasket - Burner Swing Door 100097-01 1 1 1 1
1U 1/8" Dia. Rope Gasket - Observation Port 100096-01 1 1 1 1
1V Observation Port Cover 100074-01 1 1 1 1
1W 5/16" Flat Washer, SAE, Plated 80860647 2 2 2 2
1X Socket Head Cap Screw, 5/16" x 5/8" Lg., Plated 100050-01 2 2 2 2
1Y Tap Bolt, 3/8" -16 x 1-3/4" Lg., Plated 100102-01 2 2 2 2
1Z 5/16" Flat Washer, USS, Plated 80860611 2 2 2 2
1AA Smokebox 100021-01 1 1 1 1
1BB 5/16" Flat Washer, USS, Plated 80860611 4 4 4 4
1CC Cap Screw, 5/16" -18 x 3/4" Lg., Plated 80861340 4 4 4 4
1DD 1/4" NPT Pipe Plug, Square Head, Brass 806603542 1 1 1 1
1EE Smokebox Collar
6" Dia. 100093-01 1 1 1 ---
7" Dia. 100094-01 --- --- --- 1
1FF 5/16" Flat Washer, USS, Plated 80860611 2 2 2 2
1GG Cap Screw, 5/16" -18 x 7/8" Lg., Plated 80861371 2 2 2 2
1HH Cast Iron Clean-Cut Cover (only) 100104-01 2 2 2 2
1JJ 1/2" Dia. Rope Gasket - Clean-Cut Cover 100095-01 2 2 2 2
1KK 222A Heater Carton Assembly 6036036 1 1 1 1
1LL Tapped Heater Cover Plate - Rear Heater 7036031 1 1 1 1
1MM Heater Cover Plate Gasket 8036068 1 1 1 1
1NN
Cap Screw, 3/8" -16" x 7/8" Lg., Plated,
ASME Grade SA307B
80861337 6 6 6 6
1PP 5/16" Flat Washer, SAE, Plated 80860647 6 6 6 6
