61
Item
No.
Description Part No. MST288 MST396 MST513 MST629
2. JACKET ASSEMBLY
2A Jacket Front Panel Assembly w/Insulation 100575-01 1 1 1 1
2B Power Outlet Receptacle, w/Harness 100605-01 1 1 1 1
2C
#8 x 1/2" Type AB Truss Head w/Shoulder, Sheet Metal
Screw, Plated
100038-01 10 10 10 10
2D Jacket Rear Panel Assembly w/Insulation 100578-01 1 1 1 1
2E External Wiring Enclosure 100602-01 1 1 1 1
2F Tap End Stud, 5/16" -18 x 3" Lg., Plain 100046-01 2 2 2 2
2G 5/8" O.D. x 2-5/32" Lg. Jacket Spacer 100035-01 2 2 2 2
2H Acorn Nut, 5/16" -18, Plated 100047-01 2 2 2 2
2J 3" Thick Fiberglass Insulation Wrapper
100614-03 1 1 --- ---
100614-04 --- --- 1 ---
100614-05 --- --- --- 1
2K
Jacket Left Side Panel - 3 Section 100581-03 1 1 --- ---
Jacket Left Side Panel - 4 Section 100581-04 --- --- 1 ---
Jacket Left Side Panel - 5 Section 100581-05 --- --- --- 1
2L
Jacket Right Side Panel - 3 Section 100583-03 1 1 --- ---
Jacket Right Side Panel - 4 Section 100583-04 --- --- 1 ---
Jacket Right Side Panel - 5 Section 100583-05 --- --- --- 1
2M
Jacket Top Panel - 3 Section 100585-03 1 1 --- ---
Jacket Top Panel - 4 Section 100585-04 --- --- 1 ---
Jacket Top Panel - 5 Section 100585-05 --- --- --- 1
2N Beckett Burner Plastic Enclosure Backer Plate 102233-01 1 1 1 1
2P Beckett Burner Plastic Enclosure Cover 102232-01 1 1 1 1
2Q Beckett Burner Plastic Enclosure Name Plate 102231-01 1 1 1 1
2R
Sheet Metal Screw, Plated, Phillips Truss Head,
Type AB, #8 x 1/2" Lg.
80860000 2 2 2 2
2S
Sheet Metal Screw, Plated, Phillips Pan Head,
Type B, #8 x 1/2" Lg.
80860019 1 1 1 1
To Next Page
