12. TECHNICAL FEATURES WOOD GASIFYING BOILER PyroBurn Lambda
7
8
9
10
11
12
13
14
1. Microprocessor control; 8. Chimney ue;
2. Safety heat exchanger; 9. Draught fan;
3. Thermal mineral wool insulaon; 10. Primary air ap;
4. Water jacket; 11. Secondary air ap;
5. Fuel loading chamber; 12. Cold water inlet
6. Gasicaon chamber; 13. Drainage
7. Lambda sensor 14. Hot water outlet
Diagram 19
Components of PyroBurn Lambda boiler
