12.2.Componentsofthecleaningsystem
Diagram 21. Components of the cleaning system
Table 8
No code 20 kW code30kW Model PyroBurn Lambda20-30kW
pcs.
20
kW
pcs.
30
kW
1 31480031000001 31480031000001 Rubberhandle 1 1
2 89081231000308 8908123100211 Axisofthecleaningsystem 1 1
3 89081231000304 89081231000207 Tubeofthecleaningsystem 1 1
4 - - BoltM8x35DIN933 1 1
5 89081200000373 89081231000208 Holderspirals 1 1
6 89081231000310 89081231000215 Spiralscleaningfumeexhausttubes 4 5
7 - - NutMx8DIN6923 1 1
8 - - BoltMx16DIN923 2 2
9 - - ScrewM4xDIN934 2 1
