12.1.ComponentsofthecombusonchamberofPyroBurnLambdaboiler
Diagram 20
Components of the combuson chamber of PyroBurn Lambda
Table 7
No code 20 kW code30kW Model PyroBurn Lambda20-30kW
pcs.
20 kW
pcs.
30kW
1 31080031000013 31080031000002
Sideelementofuppercombusonchamber
2 2
2 31080031000014 89080031000006
Nozzle
1 1
3 89081231000312 89080031000005
Rearelementofboomcombusonchamber
1 1
4 31080031000016 89080031000001
Boomelementofboomcombusonchamber-long
1 1
5
-
89080031000002
Boomelementofboomcombusonchamber-short
- 1
6 31080031000015 89080031000012
Sideelementofboomcombusonchamber
2 2
7 89081231000311 89081282000014
Protecvesteelplate
6 6
8 89081231000312 89081231000213
Protecvesteelplate-back
1 1
9 89081231000314 89081231000216
Protecvesteelplate-le
1 1
10 89081231000313 89081231000214
Protecvesteelplate-right
- 1
