BusLogic BT-440C User Manual

Table of Contents, continued
Section 4: Hard Drive Setup
Formatting
the Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Using
the AutoSCSI Utilities Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Format Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Verify Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
SCSI Device Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Setting
Up the Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Installing
Device Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5
Section 5: Troubleshooting
Appendix A: BT-445C Switch Settings
Introduction
The BusLogic BT-440C/445C VESA Host Adapter is an intelligent VL-Bus
to SCSI bus master host adapter based on a BusLogic-designed, MultiMas-
term ASIC technology. It provides a high-performance interconnection be-
tween the Video Electronics Standards Association’s (VESA) bus and up
to seven Small Computer System Interface 6CSI) peripheral devices. The
BT-440C/445C offers device driver support for major industry standard
operating sys terns.
BusLogic host adapters offer exceptionally high product reliability due to
reduced component count and lower power ccnsumption. Minimized
command overhead results in faster command execution. Adapter BIOS
supports up to 8 GBytes capacity per disk.
The BT-44OC is the same as the BT-445C, but without the floppy connector.
For the remainder of this manual, BT-445C refers to both models except as
noted.
Hardware Requirements
Your VESA computer needs:
n One available expansion VL slot for each BT445C being installed
n At least one 3.5” floppy drive
n DC power for an internal 3.5” SCSI drive or an external subsystem
You’ll need the following cables:
w A 50-pin cable with a high density connector to connect the BT-445C to
external devices
introduction m l-l

BusLogic BT-440C Specifications

General

Brand	BusLogic
Model	BT-440C
Category	Adapter
Language	English
