INSTRUCTION, USE AND
MAINTENANCE MANUAL
Page 53 of 61
EN
- Place the gauge as shown in the following figure:
- Press push button . Wait a few seconds until
you see the following screen:
- Place the gauge against the chuck in the lower part
of the it but on a smaller diameter than before as
indicated on the image on the monitor.
- Press push button .
On the monitor the next screen page will be dis-
played:
Measure the exact diameter of a rim (see Fig. 47) and
place it on the screen on the monitor by pressing the
or buttons.
Fig. 47
- Fit the measured wheel on the balancer and lock it
on the chuck.
LIBRAK350 - LIBRAK350PRO
1296-M024-01
