BWT Perla Silk M - 7.2 M; M Bio Specifications

24
EN
7.2 BWT Perla Silk M / M Bio*
BWT Perla Silk Type M / M Bio
Nominal connection (outside thread) BSP ¾“ (DN 20)
Nominal ow rate in accordance with EN 14743 l/h 1560
Operating pressure (min./max.) bar 1.7 / 5.0
Operating ow range (min./max.) l/min 5 / 50
Maximum ow rate * l/min 80
Quantity of ion-exchange resin l 15
Nominal capacity (EN 14743) /(CaCO3 mmol/l) m³x°dH/mol/ppm 43 / 7.7 / 770
Capacity salt reservoir kg 16
Salt consumption per regeneration kg 2.0
Water consumption per regeneration l 105
Protection class IP 51
Water temperature (min./max.) °C 5 /30
Ambient temperature (min./max.) °C 5 /40
Electrical connection V / Hz 230 / 50
Dimensions: Width x depth x height (W x D2 x H) mm 276 x 470 x 596
Connection height (A) / Overow height (S) mm 415 / 320
Operating weight, approx. kg 50
*Tested with HiFlow connection – continuous operation at this level may affect softening efciency
