6 Technical data
Technische Daten BWT THERO 90PRO
Permeate production *1) (amount produced) l/min (l/h) 1,5 l/min (96 l/h)
Salt rejection % > 98
Water conversion factor WCF (factory setting) *2), *3) % ca. 50% @ 15 °C
Min. Inlet flow l/min (l/h) min. 3,4 l/min; min. 200 l/h
Concentrate (Drain) l/min (l/h) ca. 1,6 l/min; ca. 96 l/h
Feed water pressure MPa (bar) 0,1 … 0,4 MPa (1 ... 4 bar)
Feed water, ambient temperature (min./max.) °C 5 ... 30 / 5 ... 40
Iron + manganese (Fe+Mn) mg/l < 0,05
Silicate (SiO
2
) mg/l < 15
Salt content (TDS) mg/l < 1000
Blockage index (SDI) %/min < 3
Oxidising substances mg/l < 0,05
Protection class IP 54
Electrical connection / fuse / internal fuse V/Hz/A 100–230 / 50 / 10 / 1,25 A (Typ T / „slow burn“)
Electrical power consumption (operation/standby) W 90W / < 3W
Plug standard (grounded PE mains plug) IEC-320 socket
Feedwater, permeate and concentrate
connections
inch/inch/
inch
3/4“ M; 1/4“ JG; 1/4“ JG
Dimensions: Width, depth, height (W×D×H) mm 120 × 243 × 451
Weight kg 8,5
Order number for replacement cartridge: 812829
Note: The following conditions apply for determining the nominal flow rate:
*1) The actual nominal flow rate may deviate slightly from the flow rate indicated in the
table due to fluctuations in the feedwater quality, the flow pressure, the water tempera-
ture, and the permeate counter-pressure (e.g. with great permeate pumping heights).
*2) As a general rule, the manufacturer recommends pre-treating the feedwater.
*3) The RO device is factory- configured for a WCF of about 50%.
RO module size M
The production year is
located on the bottom
side of the RO module:
(e.g. 06-2018)
1
8
W D
H
BWT THERO 90PRO
