BYD EPS14Pi - Replace Support Wheels; Replace Balance Wheels

MAINTENANCE OF VEHICLES
USER MANUAL
48
EPS14Pi
49
REPLACE SUPPORT WHEELS
(
1) Lift the front end of the fork
till the support wheel is rotated 90 degrees, and then pad
with a piece of solid wood.
(2) Unscrew the screw. Replace the support wheel and then rotate 180
degrees. Replace
another support wheel.
(3) Replace the support wheel of the fork on the other side.
12
13
81
12
SUPPORT WHEEL
4 81
HEXAGON SOCKET SET
SCREWS WITH FLAT OIN
4 90 N-m
13
BUSHING
4
(1) The support wheel should be replace completely.
(2) After the wheel is replaced, the balance of the forklift shall be checked and adjusted.
CODE PART NAME QTY
CODE PART NAME QTY
OTHER
INFORMATION
OTHER
INFORMATION
REPLACE BALANCE WHEELS
(1) Jack up the rear of the forklift and pad with solid wood. Unscrew the nut and remove the
balance wheel.
(2) Unscrew nuts and bolts and then replace balance wheels.
15
HEXAGON HEADED
B
OLT M16×160
1 20
BALANCE WHEEL
2
16 NUT M16 1 110 N-m 21
HEXAGON HEADED BOLT
M12×45
1 90 N-m
17
SLEEVE OF THE BALANCE
WHEEL
1 22 LIGHT TYPE SPRING WASHER 1
18
HEAVY TYPE SPRING
WASHER M16
1 23 FLAT WASHER 3
19
FLAT WASHER M12
1
15
16
17
18
20
20
23
23
23
19
22
21
CODE PART NAME QTY
CODE PART NAME QTY
OTHER
INFORMATION
OTHER
INFORMATION
After wheels are replaced, the balance of the entire forklift shall be checked and adjusted.
Caution
Caution
OM-EPS14Pi2019001- E N
