INTRODUCTION OF THE ENTIRE FORKLIFT
USER MANUAL
16
E
PS14Pi
17
PARAMETER TABLE OF THE ENTIRE FORKLIFT
FEATURES
MANUFACTURER BYD
MODEL EPS14Pi
OPERATING MODE (WALKING TYPE AND STAND UP)
Stand up
LOAD CAPACITY
Q（kg)
1400
LOAD CENTER DISTANCE C(mm) 600
FRONT OVERHANG X(mm) 901
WHEEL BASE y(mm) 1600
WEIGHT
TOTAL WEIGHT (BAT NTERY INCLUDED) kg 1420
AXLE LOAD WHEN MAST IS TAKEN BACK WITH FULL LOAD,DRIVE SIDE / BEARING SIDE
kg 1290/1350
AXLE LOAD WHEN MAST IS TAKEN BACK WITH NO LOAD, DRIVE SIDE / BEARING SIDE
kg 900/340
WHEEL
WHEEL，DRIVE SIDE / BEARING SIDE
POLYURETHANE
DIMENSION OF THE TIRE DRIVE SIDE Φ230X82
DIMENSION OF THE TIRE BEARING SIDE 4XΦ85X70
DIMENSION OF THE ACCESSORY WHEEL 2Xφ120X50
NUMBER OF WHEELS
(X= DRIVE WHEEL)
DRIVE SIDE / BEARING SIDE
1X+1/4
DIMENSION
HEIGHT WHERE THE MUST IS IS RETRACTED h1(mm) 2203
FREE LIFT HEIGHT h2(mm) 138
LIFT HEIGHT h3(mm) 3200
MAST HEIGHT WHEN LIFT UP h4(mm) 3717
INITIAL LIFT HEIGHT h5(mm) 120
LIFT HEIGHT OF THE BOTTOM PART h5(mm) 120
MAX/MIN HEIGHT WHERE THE OPERATING HANDLE IS LOCATED IN
THE DRIVING POSITION
h14(mm) 990/1288
RETRACTING HEIGHT OF FORK h13(mm) 90
OVERALL LENGTH l1(mm) 1729
LENGTH OF THE FORK FRAME l2(mm) 832
OVERALL WIDTH b1(mm) 800
DIMENSION OF FORK s/e/l(mm) 60/180/1150
OUTER SPACING OF THE PALLET FORK b5(mm) 560
OFF-GROUND CLEARANCE AT WHEELBASE CENTER m2(mm) 27
AISLE WIDTH (1000*1200) Ast(mm) 2628
AISLE WIDTH (800*1200) Ast(mm) 2515
(LH/ RH)
Wa(mm) 1802
PERFOR
-MANCE
DRIVING SPEED FULL LOAD/EMPTY km/h 8/9
LIFTING SPEED FULL LOAD/EMPTY mm/s 160/230
RATE OF DESCENT FULL LOAD/EMPTY mm/s 370/230
GRADEABILITY, FULL LOAD/EMPTY % 9/16
DRIVE
MOTOR
RIVE MOTOR POWER kw 1.3
LIFT MOTOR POWER kw 3
BATTERY VOLTAGE / CAPACITY V/Ah 24/270
OPERATING AND STORAGE ENVIRONMENT
TURNING RADIUS
(1) With explosive substances such as ammunition
(2) Dusty
(3) A harbor or waterfront at risk of salt erosion
(4) A chemical factory that may be affected by acid or other chemicals
(5) Containing combustible dust and gas
(6) With certain toxic substances
(7) With radioactive substances
(8) Other special environments
Please consult local forklift dealers of BYD before operating in the following environment:
Temperature： -5 ~ 40° C
Humidity ：≤90%
Altitude：≤2000m
Road surface: dry, hard, relatively flat, smoothly
Storage：be stored in a well - ventilated warehouse, but cannot be stored in the open air for
a long time.
Caution
Decrease the weight of the goods or the run-ning speed when the working condi-tion is poor.
Danger
(1) No sharp obstacles on the road.
(2) No strong acid base or strong polar solvents such as toluene and acetone on the road.
(3) Do not immerse the wheels in water for a long time.
(4) Do not expose to intense sunlight for a long time.
(5) No flammable gas, flammable dust and volatile flammable liquid in the operating environment.
Notes
