C-TEC AVAC User Manual

A
VAC VOICE ALARM SYSTEM
AVAC Installation and Maintenance Manual • Approved Document No. DAU0000402 Rev 6 • Page 12
CONNECTING THE PANEL
Connect AVAC’s internal wiring immediately prior to commissioning and after you have refit-
ted the lid, chassis mounting plate, lid/base connecting cable and earth straps by reversing the
process described on page 10.
Before connecting any wiring to the PCBs, we recommend you check all third-party equipment
(loudspeakers, emergency microphone, paging panels, background music sources, etc) to ensure
they are correctly fitted and that cable integrity is verified throughout the installation.
It is essential that the wiring and loudspeakers are tested with a Loadmaster or LCR meter to
ensure that the total load connected to each of the loudspeaker circuits is not greater than
60 watts (not less than 167 Ohms) at 1 kHz. See page 15 for important information on the
loading of loudspeaker circuits.
DO NOT use a high voltage insulation tester with any electr
onic devices connected.
www.acornfiresecurity.com
www.acornfiresecurity.com

C-TEC AVAC Specifications

Power Supply and Charger

AC input	230 V a.c +/- 10% 50/60 Hz
Internal power supply	27 V d.c. Nominal
Max continuous output current	5A @ 230 V a.c.
Pulse peak output current	7A @ 230 V a.c.
Battery size and type	2 x 12 V 7 AHr VRLA connected in series
Max Battery Charge current	0.5 A

Inputs

BGM input level	230 mV RMS
BGM with link input level	2.3 V RMS
Page input level	230 mV RMS
Page with link input level	2.3 V RMS
Fire Mic input level	230 mV RMS

Outputs

Max Output AUX 24 V	100 mA
Max Output Fire Mic 24 V	100 mA
Max Speaker Output	100 V 0.6 A RMS (60 W) x 2
Output power	2 x 60 W continuous average power
Frequency response at 30 W load	152 Hz to 12 kHz

Battery Calculations

Average standby current at full load	97 mA
Average alarm current at full load	1.2 A
Loudspeaker Monitoring Tone	20 kHz
Frequency response on Page and BGM	220 Hz to 6.2 kHz
