QT601-2 Quantec Controller
Installation & Programming Manual • Approved Document No. DNU6012001 Rev 5 • Page 6 of 42
1 MAIN 4 Display NET1
2D 1 Display 1
3D 1 StaffRoom 1
4D 2 Display 2
5D 3 Display 3
6D 4 Display 1D
7Z 1O D Light 1
82O D Light 1
93O D Light 6
10 C A Bedroom WW1
11 M A Exit WW1
12 C A Bedroom WW4
13 C A Bedroom WW2
14 C A Bedroom WW5
15 C A Lounge WW1
16 C A Bedroom WW6
17 C A Bedroom WW3
18 C B Bedroom EW7
19 C B Bathroom EW1
20 C B Bedroom EW8
21 C B Bedroom EW9
22 C B Bedroom EW10
23 C B Bedroom EW11
24 C B Bedroom EW12
25 M B Exit EW1
26 M C Exit CEN1
27 C C Annexe CEN2
28 M C Entrance CEN3
29 C D Kitchen 1
30 C D Bedroom SW14
31 C D Lounge SW2
32 C D Bedroom SW15
33 C D Bedroom SW16
34 C D Bedroom SW17
35 C D Bedroom SW18
36 C D Bedroom SW19
37 M D Exit SW1
38 R D Car Park EXT
DEVICE PLACE DESCRIPTION
Number Type Name Number
Qu
a
n
t
ec
D
EVICE ASSIGNMENT TABLE
Call Point
AREA
Display
GROUP
A
ddressable
Overdoor Light
ZONE
Max. no. of Addressable Devices = 255; Max. no. of Areas = 26; Max. no. of Groups = 32; Max. no. of Zones = 64
D = Display; Z = Addressable Overdoor Light or Sounder; C = Call Point; M = Monitor Point; R = Radio Receiver
Z
Z
The Device Assignment Table (below) can be used as a
r
eference aid when programming Quantec. However, before
programming can begin, the day-to-day requirements of the
call system must be ascertained from the client to enable the
routing relationships between the various Areas, Groups and
Zones.
Example Requirement 1: At night, when fewer staff are on
duty, calls need to go to different nursing stations than
during the day, i.e. from unmanned nursing stations to
staffed locations.
Example Solution 1: Two different routes can be programmed
into Quantec - a primary day route (to specify which call areas
sound where during daytime hours) and a night route (to
specify which call Areas sound where at night).
Quantec can be programmed to enter and exit night mode
either automatically (by an engineer), or manually (by an
a
uthorised member of staff).
