114 Operation
4.2.3 Mode2-StartingPrintandConrmingLabelRemovalwith
SignalXSTART
Figure 6 Jumper at position JP2
 Send a print job.
 Activate XSTART and hold it active.
Therstlabelwillbeprintedantransportedtothepeelposition.
 Remove the label.
 ConrmthelabelremovalwithdeactivationofXSTART.
 Activate XSTART again to start the next cycle.
XSTART
XFEH
XETE
XESP
XEDG
XDNB
XEDST
GND
RXSTART
RXFEH
RXETE
GND
STA
RUEL
P24
Figure 7 External minimal circuit at the peripheral interface for mode 2
