CAB PS5 - Present Sensor PS6 V; Present Sensor PS8

14 14
4.4 Present Sensor PS6V
PS6V is a special version of PS6 with adjustable sender of the see-through
sensor.
1
2
Adjusting the sensor:
 Loosen 2 screws (2).
 Move the sender (1) sidewards.
 Tighten 2 screws (2).
Figure 12 Adjusting the sensor
All information about PS6 in chapter 4.3 are valid for PS6V too.
4.5 Present Sensor PS8
Figure 13 Jumper at position JP4
PS8 is immediately ready for use.
 Send a print job.
Therstlabelwillbeprintedantransportedtothepeelposition.
 Remove the label.
The next label will be printed an transported to the peel position.
4 Operation
