CAB PX Q4 User Manual

21
6 Conguration
6.1.5 Cutting

Only with cutter installed!

Not at HERMES Q and PX Q!
 Start menu.
 Select Setup > Cutting.
i
Note!
The content of the menu is depending on the cutter type and described in the manual of the cutter.
6.1.6 Peeling-off

Not at EOS!

If peel-off module or I/O interface are not installed, access only with service key inserted.
 Start menu.
 Select Setup > Peeling-off.
Parameter Meaning Default
Peel-off position Shift the position of the dispensed label relative to the dispensing edge.
The setting can also be adjusted by the software.
Thesettingsofconguration and software are added together.
0.0 mm
Backfeed delay Delay time between removing the label from the peel position and the
backfeed of the label.
250 ms
Table 9 Parameters of the Setup > Peeling-off menu
