8 Diagnostic Functions
8.6 Save Print Image

Access only with external storage device!
The function Save print image
allowstostorethelastprintimageasa.pngletoanexternalstoragedevice(SDcard,
USB memory module) installed on the printer.
 Insert SD card or USB memory module.
 Start menu.
 Select Diagnostics > Save print image.
 Select the external storage device.
 Enteralename.
Thepredenednameiscomposedoftheidentier"img",date,clocktimeandthesufx".png",butmayalsobe
altered.
 Conrmtheselectionwith .The.pnglewillbestoredintherootofthestoragedevice.
Figure 25 Saved print image
