Notice!
The printhead replacement will be described for the upper printhead. The procedure applies for the lower
printhead in the same manner.
Removing the printhead
1. Lift the printhead.
2. Remove labels and transfer ribbon from the printer.
3. Lightly keep printhead mounting bracket (8) on the print roller with one nger and loosen screw (7).
4. Swivel printhead mounting bracket (8) upward.
5. Remove printhead (1) from the printhead mounting bracket (9) if necessary.
6. Loosen both plug connections (2, 3) on the printhead.
Installing the printhead
1. Attach plug connections (2, 3).
2. Position printhead in printhead mounting bracket (8) in such a way that the pins (6) are secured in the corre-
sponding holes in the printhead mounting bracket (8).
3. Lightly keep printhead mounting bracket (8) on the print roller with one nger and check for correct positioning of
the printhead in the mounting bracket (8).
4. Screw in screw (7) and tighten it.
5. Reload labels and transfer ribbon.
4 Replacing Assembly Units
