• The Detailed Display provides detailed data about one battery service or station
when the appropriate station key is pressed. For example, during a service in
Station 2, press
2
to see the following display:
Note Press or to display additional details such as warning codes, cycles,
and program phases.
• The Menu Display provides access to various functions of the analyzer when
the MENU key is pressed (see Menu Structure, page 16).
Press the MENU key and select menu functions by pressing or to scroll
through the menu and pressing ENTER when the desired function is displayed.
For example, this message shows one option in the System Security menu:
CHARGE EMPTY
3.02V Charge
Program in Progress
Current program setting for
inserted adapter
Current battery status
S2 CHARGE
1.35V/Cell 1000mA 233mΩ 32
o
C 1:14
Temperature
Station
Char
e Current
Program
Program Duration
Resistance
verage Cell
Voltage
MAIN MENU 10:52:55
System Security
Time
SYSTEM SECURITY 10:52:55
Set Security
A menu option in System Security
Cadex Electronics Inc. C7000-C Series Battery Analyzers .
