Calculated Industries ElectriCalc Pro Pocket Reference Guide

Pocket RefeRence Guide
— 23
(cont’d)
3. Set to Copper (if necessary):
(Cu/Al) 3Ø 75 Cu 3 PH
4. Enter Amps:
 AMPS 265.
5. Find Wire Size:
 AWG 300 CU WIRE SIZE
6. Change to Aluminum:
(Cu/Al)
AWG 400 AL WIRE SIZE
Sizing Parallel Conductors (Free Air)
What size 60°C insulated Copper
Wire is required for a single conductor
carrying a 500 Amp load in a Free
Air environment (30°C Ambient
Temperature.)? What size for two
Parallel conductors?
KEYSTROKE DISPLAY
 0.
1. Set to 60º C:
(60º) 60 0.
2. Set to Copper (if necessary):
(Cu/Al) 60 Cu 0.
3. Set to Free Air mode:
(FrAir) 60 Cu FrAir 0.
4. Enter Amps:
 AMPS 500.
5. Find Wire Size for one conductor:
 AWG 500 CU WIRE SIZE

Calculated Industries ElectriCalc Pro Specifications

General

Type	Scientific
Cover	Yes
Form factor	Pocket
Control type	Buttons
Product color	Yellow
Digits	8 digits
Display type	LCD
Display tilting	No
Display size (HxV)	15.88 x 63.5 mm
Display number of lines	- lines
Display size (HxV) (imperial)	0.625 x 2.5 \
Storage media type	-
Battery type	CR2016
Power source	Battery
Battery voltage	3 V
Number of batteries supported	1

Weight and Dimensions

Depth	16 mm
Width	76 mm
Height	142 mm
Weight	127.5 g
