Calculated Industries ElectriCalc Pro - Finding Voltage Drop Resistance

Pocket RefeRence Guide — 29
(cont’d)
4. Enter Amps:
 AMPS 15.
5. Enter Volts:
 VOLT 240.
6. Enter Wire Size:
* AWG 10 CU WIRE SIZE
7. Enter 3% allowable Voltage Drop:
 DROP 3.0 % V
8. Find distance:
 FEET 234.86987
Finding Voltage Drop Resistance
What is the Resistance per 1,000 Ft.
of #2 90° C Copper conductor?
KEYSTROKE DISPLAY
 0.
1. Set to 90º C:
(90º) 90 0.
2. Set to Copper (if necessary):
(Cu/Al) 90 Cu 0.
3. Enter Wire Size:
* AWG 2 CU WIRE SIZE
4. Find Resistance:

(Wire Res) OHMS 0.2033993 WIRE
KEYSTROKE DISPLAY
