Calculated Industries ElectriCalc Pro Pocket Reference Guide

Pocket RefeRence Guide — 25
(cont’d)
6. Find Wire Size for two conductors:
 PAR 000 CU WIRE SIZE
7. Exit Free Air Mode and Clear:
 60 Cu 0.
Finding Derated Wire Size
A circuit was built with 60°C Copper
wire connecting a 47,650 VA load
to a 240 Volt, 3Ø source. Ambient
Temperature is 50°C. What is the
Derated Wire Size required if eight
current-carrying THHN wires are
installed in the raceway?
KEYSTROKE DISPLAY
 0.
1. Set to 3-Phase:
  (3Ø) 3Ø 3 PH
2. Set to 60º C:
(60º) 3Ø 60 3 PH
3. Set to Copper (if necessary):
(Cu/Al) 3Ø 60 Cu 3 PH
4. Enter Volt-Amps:
 VA 47,650.
5. Enter Volts:
 VOLT 240.
6. Find Amps:
 AMPS 114.62808.
KEYSTROKE DISPLAY

Calculated Industries ElectriCalc Pro Specifications

General

Type	Scientific
Cover	Yes
Form factor	Pocket
Control type	Buttons
Product color	Yellow
Digits	8 digits
Display type	LCD
Display tilting	No
Display size (HxV)	15.88 x 63.5 mm
Display number of lines	- lines
Display size (HxV) (imperial)	0.625 x 2.5 \
Storage media type	-
Battery type	CR2016
Power source	Battery
Battery voltage	3 V
Number of batteries supported	1

Weight and Dimensions

Depth	16 mm
Width	76 mm
Height	142 mm
Weight	127.5 g
