Pocket RefeRence Guide
— 27
(cont’d)
3. Set to Copper (if necessary):
(Cu/Al) 3Ø 75 Cu 3 PH
4. Enter Amps:
 AMPS 20.
5. Enter Volts:
 VOLT 208.
6. Enter Length:
 FEET 175.
7. Enter allowable VD%:
 DROP 3.0 % V
8. Find Wire Size:
 AWG 8 CU VD WIRE SIZE
Finding Voltage Drop Distance
How far from a Three-Phase 240
Volt source can you install a 15 Amp
load using 60°C #10 Copper branch
circuit conductors? Assume a 3%
allowable Voltage Drop.
KEYSTROKE DISPLAY
 0.
1. Set to 3-Phase:
(3Ø) 3Ø 3 PH
2 Set to 60º C:
(60º) 3Ø 60 3 PH
3. Set to Copper (if necessary):
(Cu/Al) 3Ø 60 Cu 3 PH

Calculated Industries ElectriCalc Pro Specifications

General

Type	Scientific
Cover	Yes
Form factor	Pocket
Control type	Buttons
Product color	Yellow
Digits	8 digits
Display type	LCD
Display tilting	No
Display size (HxV)	15.88 x 63.5 mm
Display number of lines	- lines
Display size (HxV) (imperial)	0.625 x 2.5 \
Storage media type	-
Battery type	CR2016
Power source	Battery
Battery voltage	3 V
Number of batteries supported	1

Weight and Dimensions

Depth	16 mm
Width	76 mm
Height	142 mm
Weight	127.5 g
