55
1002595 ISSUE 5 M172 VARIHEAT
5.1 LPHW HEATING DATA - VARIHEAT WITH STANDARD AIR HEATER
flow °C 80 70 60 50 45
AA600 standard air heating capacity kW 11.0 8.8 6.6 4.4 3.3
recommended boiler capacity kW 11.0 8.8 6.6 4.4 3.3
LPHW flow rate L/min 10 10 10 10 10
return temperature °C 64.2 57.4 50.5 43.7 40.3
flow °C 80 70 60 50 45
AA900 standard air heating capacity kW 13.5 10.8 8.1 5.4 4.1
recommended boiler capacity kW 13.5 10.8 8.1 5.4 4.1
LPHW flow rate L/min 10 10 10 10 10
return temperature °C 60.7 54.5 48.4 42.3 39.2
flow °C 80 70 60 50 45
AA1200 standard air heating capacity kW 24.0 19.2 14.4 9.6 7.2
recommended boiler capacity kW 24.0 19.2 14.4 9.6 7.2
LPHW flow rate L/min 22 22 22 22 22
return temperature °C 64.4 57.5 50.6 43.7 40.3
flow °C 80 70 60 50 45
AA1500 standard air heating capacity kW 28.0 22.4 16.8 11.2 8.4
recommended boiler capacity kW 28.0 22.4 16.8 11.2 8.4
LPHW flow rate L/min 22 22 22 22 22
return temperature °C 61.8 55.4 49.1 42.7 39.5
°C 65 60 55 50 45
AA600 upgraded air heating capacity kW 12.8 11.0 9.2 7.3 5.5
recommended boiler capacity kW 12.8 11.0 9.2 7.3 5.5
LPHW flow rate L/min 14 14 14 14 14
LPHW return temperature °C 51.9 48.7 45.6 42.5 39.4
°C 65 60 55 50 45
AA900 upgraded air heating capacity kW 15.8 13.5 11.3 9.0 6.8
recommended boiler capacity kW 15.8 13.5 11.3 9.0 6.8
LPHW flow rate L/min 14 14 14 14 14
LPHW return temperature °C 48.9 46.2 43.5 40.8 38.1
°C 65 60 55 50 45
AA1200 upgraded air heating capacity kW 28.0 24.0 20.0 16.0 12.0
recommended boiler capacity kW 28.0 24.0 20.0 16.0 12.0
LPHW flow rate L/min 44 44 44 44 44
LPHW return temperature °C 55.9 52.2 48.5 44.8 41.1
°C 65 60 55 50 45
AA1500 upgraded air heating capacity kW 32.7 28.0 23.3 18.7 14.0
recommended boiler capacity kW 32.7 28.0 23.3 18.7 14.0
LPHW flow rate L/min 44 44 44 44 44
LPHW return temperature °C 54.4 50.9 47.4 43.9 40.4
Data based on air 30°C, pool water 28°C
5.2 LPHW HEATING DATA - VARIHEAT WITH UPGRADED AIR HEATER
(WHERE MODEL NUMBER INCLUDES +EC LPHW)
