EN
Page 16 / 72 E-MPSM Rev1 - Operating Instructions
12. ALARMS
Error reset can be automatic or manual, depending on the error that occurs. Manual reset is carried out using the
enter button and then start to restart the pump.
Code Description
Reset ERR
Causes
Er01 Blockage due to no water MAN
The device is in failure due to no water.
The system try to restart automatically and make one
attempt every 10 minutes for 7 times.
Er02 Faulty pressure sensor – Max. ressure exceeded MAN Faulty pressure sensor
Er03 Blockage due to low supply voltage AUT
Supply voltage lower than 195V.
- The system automatically restart when the clamp
voltage is higher than 205V.
Er04 Blockage due to high rectied voltage AUT
Supply voltage higher than 225V.
- The system automatically restart when the clamp
voltage is lower than 225V.
Er05 Blockage due to exceeded of number of starts MAN The system has started more than 240 times in 2 hours
Er06 Blockage due to overpower in the electro pump MAN
Er07 Blockage due to overcurrent in the electro pump motor MAN
The system try to restart automatically and make one
attempt every 10 seconds for 3 times.
Er08 Blockage due to internal overheating AUT
Er09 Blockage due to overpressure MAN
Er10 Thermal-protector intervention detected MAN Motor overheating
Er11 Internal hardware error AUT
11.2. ESIGNATION OF PARTS
Nr. Designation
12.01 Delivery casing
12.10 Valve set
12.20 Screw
14.02 External jacket
14.20 O-ring
14.80 Vent valve and ball
14.83 O-ring
15.50 Suction strainer
15.70 Screw
25.01 First stage casing
25.02 Stage casing
25.05 Last stage casing
25.20 Preload ring stages
25.22 O-ring
25.24 Support ring preload
25.28 Screw
25.30 Circlip
25.32 Screw - Washer
28.00 Impeller
28.04 Impeller nut
28.08 Washer
34.03 Oil chamber cover
34.08 Plug
34.09 O-ring
34.12 Screw
34.13 O-ring
36.00 Mechanical seal
36.51 Retaining ring, split
36.52 Shoulder ring
70.00 Motor cover, pump side
70.08 O-ring
70.09 O-ring
70.12 Cable gland rubber ring
70.13 Washer
70.16 Cable gland
70.20 Screw
70.23 O-ring
72.00 Upper mechanical seal
72.02 Circlip
73.00 Pump side bearing
76.01 Motor jacket with winding
76.62 Jacket cover
78.00 Shaft with rotor packet
81.00 Bearing
82.02 Screw
82.03 O-ring
82.04 Compensating spring
82.05 Screw
82.11 Screw
82.30 Plug
94.00 Capacitor
96.00 Cable
96.02 Cable with plug
96.15 Control box
98.51 Transducer
98.52 Signals cable
98.53 Main power cable
98.55 Terminal box cover with board
