p. 20 - Manual FA01208-EN - 07/2021 - © CAME S.p.A. - Translated original instructions
F5 Safety test
After every opening or closing command, the board will check whether the photocells are working properly.
The safety test is always active for wireless devices.
This function only appears if the photocells have been enabled.
0= Deactivated (default) / 1=CX / 2=CY / 4=CX+CY
F6 Maintained action
The gate opens and closes by keeping the button pressed. Opening button on contact 2-3P and closing
button on contact 2-7. All other control devices, even radio-based ones, are excluded.
OFF (default) / ON
F7 Command [2-7]
From the control device connected to 2-7 it performs the step-step (open-close-invert) or sequential (open-
stop-close-stop) command.
0 = Step-step (default) / 1 = Sequential
F9
Obstruction detection
with motor stopped
With the gate closed, opened or totally stopped, the gearmotor stays idle if the safety devices, that is,
photocells or sensitive safety-edges detect an obstruction.
OFF (default) / ON
F10
Gate state warning
output
It signals the gate status. The signal device is connected to contact 10-5.
0 = Lit when gate is open or moving (default) / 1 = when opening it fl ashes intermittently every half-
second, when closing it fl ashes intermittently every second, stays lit when gate is open, is o when
gate is closed.
F14 Sensor type
Setting the type of accessory for controlling the operator.
0 = command with transponder sensor or magnetic card reader / 1 = command with keypad selector
(default)
F18 Additional light
Output for connecting the additional light onto 10-EX:
Outdoor light for additional visibility in the drive way.
Cycle light that stays lit from the moment the gate starts opening until it completely closes, including the
automatic closing waiting time.
Courtesy light that stays on for an adjustable time of between 60 and 180 seconds. To set the time, see
function F25.
OFF (default) / 1 = Cycle / 2 = Courtesy
F19
Automatic Closing
Time
The automatic-closing wait starts when the opening limit switch point is reached and can be set to between
1 and 180 seconds. The automatic closing does not work if any of the safety devices trigger when an
obstruction is detected, or after a total stop, or during a power outage.
OFF (default) / 1 = 1 second /... / 180 = 180 seconds
F20
Automatic closing time
after partial opening
The wait before the automatic closing starts after a partial opening command for a time of between 1 s
and 180 s. The automatic closing does not work if any of the safety devices trigger when an obstruction is
detected, or after a total stop, or during a power outage.
OFF / 1 = 1 second /... / 10 = 10 seconds (default) / 180 = 180 seconds
F21 Pre-fl ashing time
Adjusting the pre-fl ashing time for the fl ashing light connected to E1-W, before each maneuver. The fl ashing
time is adjustable from one to ten seconds.
OFF
(default) / 1 = 1 second /... / 10 = 10 seconds
F25 Courtesy light time
Additional (courtesy) light, stays lit for the necessary time while the gate is opening and closing.
It can be set to between 60 and 180 seconds.
60 = 60 seconds (default)/... / 180 = 180 seconds
F49
Managing the serial
connection
To enable the paired operating mode or the CRP (Came Remote Protocol).
OFF (default) / 1 = Paired / 3 = CRP
F50 Saving data
Saving memorized users and settings in the memory roll.
This function only appears if a memory roll has been fi tted into the control board.
OFF (default) / ON
F51 Reading of data
Uploading data saved in memory roll.
This function only appears if a memory roll has been fi tted into the control board.
OFF (default) / ON
F52
Transferring
parameters in paired/
alternate mode
Uploading settings from Master to Slave.
This appears only if function F49 is set to PAIRED.
OFF (default) / ON
F54 Openingdirection
For setting the gate opening direction.
0 = Opening left (default) / 1 = Opening right
