04/2014 © CAME cancelli automatici s.p.a. - The data and information in this manual may be changed at any time and without obligation on the part of Came Cancelli Automatici S.p.a. to notify said changes.
ITALIANITALIANENGLISH
5.7 Manually releasing the gearmotor
- Insert the key into the lock and turn it clockwise, ....
5.6 Fastening the endstop tabs.
Position the endstop tabs onto the rack and fasten them with the 3 mm Allen wrench key. Their position, marks the limit of the gate
runs.
Note:avoid that the gate strikes the mechanical stop, whether when closing or opening.
Mechanical stop
WARNING: opening the release door
prevents the motor from working.
Trilobe key
Release handle
... open the inspection door and turn the release handle counter-clockwise.
