CAME BX-68B User Manual

Dir/DeltaS
Delta
R X
RX
R X
RX
T X
TX
T X
TX
p.
14
14 - Manual code:
119BV85
119 BV8 5 ver.
2
04/2014 © CAME cancelli automatici s.p.a. - The data and information in this manual may be changed at any time and without obligation on the part of Came Cancelli Automatici S.p.a. to notify said changes.
ITALIANITALIANENGLISH
(N.C.) contact.) total stop»
- Input for safety devices like photocells, compliant with law EN
12978. Stops gate if it is moving and then automatically closes
it (if this function is selected).
Safety devices
Photocells
(N.C.) contact.) re-open when closing »
- Input for safety devices like photocells, compliant with law EN
12978. While the gate is closing, opening the contact will invert
movement until it is fully opened.
(N.C.) contact.) total stop»
(N.C.) Contact Re-open when closing»
Photocells
if unused
if unused
