CAME BXV10AGF

p. 21 - Manual FA01719-EN - 03/2022 - © CAME S.p.A. - Translated original instructions
F35
Slow-down
sensitivity
Adjusting obstruction detection sensitivity during slow-down.
10 = maximum sensitivity / … / 100 = minimum sensitivity (default)
F36
Adjusting the
partial opening
Adjustment as a percentage of total travel, during gate opening.
 This function appears only is the Encoder function is activated.
10 = 10% of the gate travel (default) / … / 80 = 80% of the door travel
F37
Opening slow-
down point
Percentage adjustment of the total door travel, of the opening slow-down starting point.
 This function appears only is the Encoder function is activated.
10 = 10% of the gate-leaf travel / … / 25 = 25% of the gate-leaf travel (default) / …
/ 60 = 60% of the gate-leaf travel
F38
Closing slow-
down point
Percentage adjustment of the total door travel, from the closing slow-down starting
point.
 This function appears only is the Encoder function is activated.
10 = 10% of the gate-leaf travel / … / 25 = 25% of the gate-leaf travel (default) / …
/ 60 = 60% of the gate-leaf travel
F49
Managing
the serial
connection
To enable the paired operating mode or the CRP (Came Remote Protocol).
0 = Deactivated (default) / 1 = Paired / 3 = CRP
F50 Saving data
Saving users and settings saved in the Memory Roll.
 This function only appears if a Memory Roll has been plugged into the control
board.
0 = Deactivated (default) / 1 = Activated
F51
Reading of
data
Uploading data saved in the Memory Roll.
 This function only appears if a Memory Roll has been plugged into the control
board.
0 = Deactivated (default) / 1 = Activated
F52
Transferring
parameters in
paired mode
Uploading settings from Master to Slave.
 This appears only if function F49 is set to Paired.
OFF = Deactivated (default) / ON = Activated
F54
Opening
direction
For setting the gate opening direction.
OFF = Opening left (default) / ON = Opening right
F56
Peripheral
number
To set the peripheral's number from 1 to 255 for each control board when you have a
system with several operators.
1 ----> 255
F63
Changing COM
speed
For setting the communication speed used in the CRP (Came Remote Protocol)
connection system.
0 = 1200 Baud / 1 = 2400 Baud / 2 = 4800 Baud / 3 = 9600 Baud / 4 = 14400 Baud
/ 5 = 19200 Baud / 6 = 38400 Baud (default) / 7 = 57600 Baud / 8 = 115200 Baud
F65
Wireless input
RIOED8WS [T1]
Wireless safety device (RIOED8WS) associated to a function of choice among those
available: P0 = TOTAL STOP, P7 = reopening during closing, P8 = reclosing during
opening.
For programming, see the instructions that come with the accessory.
 This function only appears if the RIOCN8WS card is plugged into the control board.
OFF = Deactivated (default) / P0 / P7 / P8
